Pi Picoduino RP2040

Description   The RP2040 Picoduino UNO Development Board is an Arduino UNO-compatible board featuring the RP2040 dual-core processor and built-in WiFi, offering 14 digital I/O pins, 6 analog inputs, and USB drag-and-drop programming. ideal for IoT and connected projects. Key Features Microcontroller: Raspberry Pi RP2040, Dual-core Cortex-M0+ @ 133 MHz Memory: 264KB SRAM, 2MB Flash Wireless: Built-in WiFi (802.11 b/g/n/e/i) via Infineon CYW43439 I/O: 14 Digital pins (6 PWM), 6 Analog input pins     Technical Specifications Product Name: RP2040 Picoduino Development Board Microcontroller: Raspberry Pi RP2040

• Features a dual-core Cortex-M0+ processor, running at up to 133 MHz
• Integrated with 264KB of SRAMand 2MB of Flash memory

USB Interface: Uses a square USB (Type-B) connector  Connectivity:

• Built-in WiFi support
• Compatible with 11 b/g/n/e/i wireless standards

Input/Output Ports:

• 14 digital I/O pins, including 6 PWM-capable outputs
• 6 analog input channels

Power Supply: Operates on DC input between 7V and 12V  Dimensions: 76 × 53 × 14 mm   Applications -Industrial machinery and automation systems -Portable handheld devices -Surveillance and security systems -Consumer and household electronics Datasheet: For detailed technical information, refer to the RP2040 Datasheet.
