AT89C2051
11 sold in last 24 hours
The AT89C2051 is a low-voltage, high-performance CMOS 8-bit microcontroller with 2KB of Flash programmable and erasable read-only memory (PEROM). It is designed with advanced architecture to deliver a high level of performance and efficiency in a compact form. Ideal for a variety of embedded applications, the AT89C2051 offers robust functionality with minimal power consumption.
Key Features:
- 8-bit CPU: Compatible with MCS-51 products.
- Memory: 2KB of Flash PEROM, 128 bytes of RAM.
- I/O Ports: 15 programmable I/O lines.
- Timers: Two 16-bit timer/counters.
- Interrupts: Six interrupt sources.
- Serial Communication: UART.
- Oscillator: On-chip oscillator and clock circuitry.
- Architecture: 8-bit
- Operating Voltage: 2.7V to 6.0V
- Operating Frequency: Up to 24 MHz
- Memory:
- Flash: 2KB
- RAM: 128 bytes
- I/O Pins: 15
- Timers: 2x 16-bit
- Serial Ports: 1x UART
- Interrupts: 6
- Oscillator: On-chip, supports external clock source
- Package Type: 20-pin PDIP/SOIC
- Consumer electronics
- Industrial automation
- Home appliances
- Data acquisition systems
- Robotics
- Educational projects
- Programming: Program the microcontroller using an appropriate programmer with support for AT89C2051.
- Power Supply: Connect to a suitable power source within the operating voltage range.
- Circuit Integration: Integrate with your project circuit, utilizing the I/O pins, timers, and serial communication as needed.
- Operation: Load and execute your application code, utilizing the built-in peripherals and features of the AT89C2051.
- Ensure the power supply voltage is within the specified range to avoid damage.
- Handle the microcontroller with care to prevent static discharge and damage to the pins.
- Verify all connections and circuit design before powering on.
