LM723 Precision voltage Regulator
6 sold in last 24 hours
The LM723 is a precision voltage regulator designed to provide stable and reliable voltage regulation in various electronic circuits. This IC offers excellent performance in maintaining a constant output voltage, making it ideal for use in power supplies, voltage reference circuits, and other applications requiring precise voltage control.
Key Features:
- Precision voltage regulation with high accuracy
- Adjustable output voltage from 2V to 37V
- High current output capability
- Built-in thermal overload protection
- Short-circuit protection
- Wide input voltage range
- Stable operation with external components
- Package Type: TO-220, TO-3
- Input Voltage Range: 4V to 40V DC
- Output Voltage Range: Adjustable from 2V to 37V
- Output Current: Up to 2.5A
- Regulation: ±0.1% (typical)
- Thermal Overload Protection: Yes
- Short-Circuit Protection: Yes
- Operating Temperature Range: -40°C to +125°C
- Power supply circuits
- Voltage reference circuits
- Regulated power adapters
- Battery chargers
- Audio amplifiers
- Configure the LM723 with external resistors and capacitors to set the desired output voltage.
- Ensure proper heat dissipation with an appropriate heatsink if operating at high currents.
- Connect the input voltage within the specified range and connect the output as needed for your application.
- Implement necessary thermal management and ensure proper circuit design to maintain stability.
- Avoid exceeding the maximum input voltage to prevent damage.
- Ensure proper heat dissipation to avoid overheating.
- Verify all connections and component values before powering the circuit.
