The MAX813L is a precision voltage monitor and timer designed for low-voltage monitoring applications. It provides a reliable means of monitoring and timing functions in a compact, low-power package. The MAX813L is often used in battery-powered devices, microcontroller systems, and other applications where accurate timing and monitoring are crucial for system operation and reliability.
Key Features:
- Precision voltage monitoring with adjustable threshold.
- Integrated timing function with adjustable delay.
- Low power consumption for battery-operated applications.
- Accurate and stable performance over a wide temperature range.
- Simple to use with minimal external components required.
- Available in a small, space-saving package.
Technical Specifications:
- Supply Voltage Range: 1.0 V to 5.5 V.
- Threshold Voltage Range: Adjustable, typically from 1.0 V to 4.5 V.
- Timing Range: Adjustable from microseconds to seconds (based on external components).
- Current Consumption: Typically in the microampere range.
- Operating Temperature Range: -40°C to +125°C.
- Package Types: Available in various surface-mount and through-hole packages.
Applications:
- Battery-powered devices requiring low-voltage monitoring.
- Microcontroller systems needing precise timing functions.
- Power management systems where voltage thresholds and timing are crucial.
- Systems requiring reliable reset or timeout functions.
Usage:
- Used for monitoring voltage levels and triggering actions based on these levels.
- Ideal for implementing delay functions and timing applications in electronic circuits.
- Suitable for use in both low-power and high-temperature environments.
Caution:
- Ensure proper connection of external timing components to achieve desired timing intervals.
- Verify threshold voltage settings to match application requirements.
- Adhere to absolute maximum ratings to avoid damage to the device.
Datasheet:
For detailed specifications, pin configuration, and design recommendations, refer to the MAX813L datasheet.
No Specifications
