Description
The ESP32 Development Board is a powerful and versatile microcontroller board designed for IoT (Internet of Things) and embedded applications. Based on the ESP32 microcontroller by Espressif Systems, it features integrated Wi-Fi and Bluetooth capabilities, making it ideal for a wide range of wireless communication projects. The ESP32 Development Board is suitable for both beginners and experienced developers due to its rich feature set and extensive community support.
Key Features
- Microcontroller: ESP32
- Wireless Connectivity: Integrated Wi-Fi (802.11 b/g/n) and Bluetooth (v4.2 BR/EDR and BLE)
- CPU: Dual-core Tensilica LX6 processor
- Operating Voltage: 3.3V
- Flash Memory: 4 MB (varies by model)
- SRAM: 520 KB
- GPIO Pins: 36 (varies by model)
- Interfaces: UART, SPI, I2C, I2S, PWM, ADC, DAC
- Power Management: Ultra-low power management modes
- Integrated Sensors: Hall sensor, temperature sensor
Specification
- Microcontroller: ESP32-D0WDQ6 or ESP32-D0WD
- Clock Speed: Up to 240 MHz
- Flash Memory: 4 MB (varies by model)
- SRAM: 520 KB
- GPIO Pins: 36 (varies by model)
- Analog Inputs: 18 channels of 12-bit SAR ADCs
- Digital-to-Analog Converter (DAC): 2 channels of 8-bit DACs
- PWM Channels: 16
- UART: 3
- SPI: 4
- I2C: 2
- I2S: 2
- Dimensions: Typically around 50 mm x 25 mm (varies by model)
Application
- IoT Projects: Ideal for home automation, smart sensors, and connected devices.
- Wearables: Suitable for developing wearable devices with wireless connectivity.
- Prototyping: Excellent for rapid prototyping of electronic projects.
- Embedded Systems: Useful in creating embedded systems with advanced capabilities.
- Robotics: Can be used in robotics for communication and control tasks.
- Education: Great for teaching electronics and programming concepts.
Datasheet:
For detailed technical information, refer to the ESP32 Development Board Datasheet provided by Espressif Systems or the specific board manufacturer.
