Description
The Red Piranha LED Module is a high-brightness indicator board using a 5mm Piranha-style LED. Known for its wide viewing angle and intense luminosity, this module is ideal for visual alerts, power indicators, or decorative lighting in Arduino and embedded projects.
Key Features
- Ultra-Bright Output: Intense red illumination
- Piranha LED Package: Wide-angle, high-durability housing
- Plug-and-Play: 3-pin interface for easy connection
- Wide Voltage Compatibility: Works with 3.3V to 5V systems
- Compact Module: Small size for panel or board mounting
- Onboard Resistor: Current-limited for safe direct use
Specification
- LED Type: 5mm Red Piranha LED
- Color: Red (typically ~625–630 nm wavelength)
- Operating Voltage: 3.3V – 5V DC
- Current Draw: ~10–20 mA
- Viewing Angle: ~120°
- Luminous Intensity: ~800–1000 mcd (typical)
- Interface: 3-pin (VCC, GND, Signal)
- Module Size: ~18 mm × 10 mm
- Weight: ~2 g
Application
- Status or power indicators
- Light signaling systems
- DIY electronics and robotics
- Visual alert modules
- Embedded lighting effects
