    The RCWL-1605 Ultrasonic Transceiver is a compact, integrated ultrasonic ranging module designed for high-efficiency, low-power distance measurement applications. Fully compatible with the widely-used HC-SR04 interface, it supports multiple output modes including UART, I2C, 1-Wire, and GPIO, making it highly adaptable for embedded systems, robotics, and IoT solutions.

    Key Features:

    • HC-SR04 Compatibility: Drop-in replacement with added features

    • Multiple Output Modes: UART, I2C, GPIO, 1-Wire supported

    • Low Power Usage: Only 2mA current draw, ideal for battery-powered devices

    • Reliable Range Sensing: 25 cm blind zone with a 4.5 m detection range

    • Built-In Smart Chip: Uses proprietary RCWL-9625 for enhanced performance

    • Wide Voltage Support: Operates between 2.8V and 5.5V

    Specifications:

    • Model: RCWL-1605

    • Chipset: RCWL-9625

    • Operating Voltage: 2.8V – 5.5V

    • Operating Current: 2mA (ultra-low power)

    • Blind Area: 25 cm

    • Max Range: 4.5 meters (typical)

    • Output Modes: GPIO (default HC-SR04 mode), UART (9600 bps, N, 1), I2C, 1-Wire

    • Compatibility: HC-SR04 protocol

    • Trigger Signal: ≥10µs HIGH pulse on TRIG pin

    • Echo Output: Pulse width proportional to distance

    • Interface Configuration: Resistor-selectable output modes

    Applications:

    • Robotics and obstacle detection

    • Smart bins and proximity-based automation

    • Reverse parking sensors or smart vehicles

    • Industrial distance measurement and automation

    • IoT devices with smart sensing capabilities
