Description
The 2.2-inch color LCD module is a compact and vibrant TFT display designed for embedded systems and portable electronics. With a 240×320 pixel resolution and 65K color depth, it delivers clear and vivid visuals in a small footprint. Its wide viewing angle and low power consumption make it ideal for handheld devices, consumer products, and educational projects.
Key Features
- 2.2-inch TFT LCD color display
- High-resolution (240×320 pixels) for sharp and bright visuals
- Supports 65K colors (16-bit RGB)
- Wide 160° viewing angle for clear visibility from different directions
- Compatible with SPI or parallel interface (varies by model)
- Easy integration with Arduino, ESP32, Raspberry Pi, and other microcontrollers
- Low power consumption and efficient backlighting
- Compact, durable design for space-constrained applications
Specification
- Display Type: TFT LCD
- Screen Size: 2.2 inches
- Resolution: 240 × 320 pixels
- Color Depth: 65K (16-bit RGB)
- Interface: SPI / Parallel (depending on model)
- Operating Voltage: 3.3V – 5V
- Backlight: LED
- Viewing Angle: 160° (H/V, typical)
- Dimensions: Approx. 50mm × 60mm × 6mm
- Weight: ~25g
Application
- Portable and handheld electronic devices
- Consumer electronics and display modules
- Industrial and control system interfaces
- DIY electronics and prototyping
- Home automation and IoT displays
- Educational and STEM development kits
Usage
- Connect the display to your microcontroller using SPI or parallel interface pins.
- Power the module using 3.3V–5V DC.
- Install the appropriate driver/library for your board (e.g., Adafruit_ILI9341 for Arduino).
- Initialize the display and send graphical or textual data for rendering.
- Customize display output to suit your application (UI, graphs, images, etc.)
Caution
- Handle the display carefully to prevent screen or connector damage.
- Ensure correct voltage levels and wiring to avoid hardware failure.
- Follow manufacturer recommendations for reliable and long-term operation.
Datasheet: For detailed technical specifications, refer to the 2.2-Inch Colored LCD Datasheet.
