RXB6 433MHz superheterodyne wireless receiver module

Description: The RXB6 433MHz Superheterodyne Wireless Receiver Module is a compact and efficient RF (Radio Frequency) receiver module designed for wireless communication applications operating at 433MHz frequency. It employs superheterodyne architecture, enhancing sensitivity and reliability in receiving data signals over relatively long distances. This module is widely used in remote control systems, wireless data transmission, and other applications requiring reliable RF communication. Key Features:

• High sensitivity superheterodyne receiver
• Operating frequency: 433MHz
• Low power consumption
• Wide operating voltage range
• Stable performance with high anti-interference capability
• Easy integration with microcontrollers and other digital systems
• Compact size for flexible installation

Technical Specifications:

• Operating Frequency: 433MHz
• Receiver Sensitivity: Typically -105dBm
• Supply Voltage: Typically 5V DC
• Current Consumption: Typically 3.5mA
• Modulation: ASK/OOK
• Data Rate: Up to 10kbps
• Interface: Digital output (TTL level)
• Dimensions: Compact module size
• Weight: Lightweight for easy handling

Applications:

• Remote control systems
• Wireless data transmission
• Home automation
• Remote sensing and monitoring
• IoT (Internet of Things) applications
• Industrial control and monitoring

Datasheet: For detailed technical information, refer to the RXB6 433MHz Superheterodyne Wireless Receiver Module Datasheet.
