CD4016 bidirectional FET switch
The CD4016 is a CMOS analog switch integrated circuit featuring four independent bilateral switches. It is designed for both analog and digital signal applications, offering low ON-resistance and high ON/OFF ratio for efficient signal routing, switching, and multiplexing tasks.
Key Features:
- Four independent bilateral switches
- Low ON-resistance: typically 80 ohms at V_DD = 10V
- High ON/OFF ratio
- Wide supply voltage range: 3V to 15V
- Low power consumption
- TTL and CMOS logic level compatibility
- Logic Family: CMOS
- Number of Switches: 4
- Supply Voltage Range: 3V to 15V
- Maximum Clock Frequency: 12 MHz at V_DD = 10V
- Power Dissipation: 500 mW
- Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Output Voltage (V_OH): V_DD - 0.05V min
- Analog signal switching
- Digital signal routing
- Multiplexing
- Data acquisition systems
- Audio and video signal processing
