HT7530A-1 Voltage regulator
The HT7530A-1 is a high-performance, low-power voltage regulator designed by Holtek. This device is designed to provide a stable output voltage with minimal noise and ripple. It is suitable for a variety of applications, including portable electronics, battery-powered devices, and other systems requiring a reliable voltage supply. The HT7530A-1 is available in a compact SOT-89 package, making it ideal for space-constrained designs.
Key Features:
- Low quiescent current
- High output voltage accuracy
- Low dropout voltage
- Overcurrent protection
- Thermal shutdown protection
- Compact SOT-89 package
- Input Voltage Range: 2.5V to 12V
- Output Voltage: 3.0V (±2%)
- Output Current: 100mA
- Dropout Voltage: 100mV (typical)
- Quiescent Current: 2μA (typical)
- Line Regulation: 0.1%/V (typical)
- Load Regulation: 20mV (typical)
- Package Type: SOT-89
- Operating Temperature Range: -40°C to +85°C
- Portable electronics
- Battery-powered devices
- Microprocessor power supplies
- Sensor power supplies
- Low-noise analog circuits
