MC68B09CP
Description:
The MC68B09CP is an enhanced version of the Motorola 6809 8-bit microprocessor, offering improved performance and additional features compared to its predecessor. It is known for its efficient instruction set and versatile addressing modes, making it suitable for a wide range of applications, including embedded systems, industrial control, and educational purposes.
Key Features:
- Enhanced 6809 instruction set
- 1.5 MHz clock speed (MC68B09)
- Dual 8-bit accumulators (A and B)
- 16-bit index and stack pointers
- 16-bit direct page register
- Multiply and divide instructions
- Fast interrupt processing
- Powerful addressing modes (immediate, direct, extended, indexed, relative)
- Low power consumption
- Package Type: PDIP-40
- Supply Voltage: 5V ± 5%
- Maximum Clock Frequency: 1.5 MHz
- Operating Temperature Range: 0°C to +70°C
- Data Bus Width: 8-bit
- Address Bus Width: 16-bit
- Instruction Cycle Time: 667 ns at 1.5 MHz
- Dimensions: 52.58 mm x 13.71 mm x 4.83 mm
- Weight: 6.5 g
- Embedded Systems: Suitable for embedded control and processing applications.
- Industrial Control: Used in industrial automation and control systems.
- Educational: Ideal for teaching microprocessor concepts and assembly language programming.
- Consumer Electronics: Integrated into various consumer electronic devices for control and processing tasks.
- Retro Computing: Popular in vintage computing and hobbyist projects.
