Description
The 5V 10A Power Supply (50W) is a reliable and efficient power source designed to deliver a stable 5V DC output with up to 10A of current. Built for performance and durability, it is ideal for powering Raspberry Pi boards, Arduino projects, LED strips, communication devices, and other 5V electronics. With built-in protection against over-voltage, over-current, and short circuits, this power supply ensures the safety and longevity of your connected devices.
Key Features
- Stable 5V Output: Provides a consistent and regulated 5V DC output for sensitive electronics
- High Current Capacity: Delivers up to 10A for powering multiple devices or high-demand applications
- Comprehensive Protection: Includes over-voltage, over-current, and short-circuit protection
- Universal Input Voltage: Operates on 100–240V AC, suitable for global use
- Efficient Design: High efficiency for dependable and energy-saving operation
- Cooling System: Equipped with built-in cooling fan or passive heat dissipation for stable performance
- Certified Safety: CE, FCC, and RoHS compliant for quality assurance
Specification
- Output Voltage: 5V DC ±5%
- Output Current: 10A
- Power Output: 50W
- Input Voltage: 100–240V AC, 50/60Hz
- Ripple & Noise: ≤ 120mV
- Load Regulation: ±2%
- Line Regulation: ±1%
- Operating Temperature: -10°C to +60°C
- Storage Temperature: -20°C to +85°C
- Humidity: 0% to 95% (non-condensing)
- Dimensions: Approx. 115mm × 50mm × 30mm
- Weight: ~200g
- Connector Type: 5.5mm × 2.1mm DC barrel jack
- Cable Length: Approx. 1.2 meters
Application
- Single-Board Computers: Ideal for powering Raspberry Pi, Arduino, ESP32, and similar boards
- LED Lighting Projects: Suitable for powering 5V LED strips, displays, and signage
- DIY Electronics: Perfect for makers, students, and hobbyists working on custom electronic builds
- Industrial Automation: Reliable power source for small control systems and embedded devices
- Communication & Networking: Can power routers, modems, and other 5V communication equipment
