    The 100A High Power MOSFET Switch Module is a heavy-duty electronic switch built for high-current DC control in power-intensive applications. Designed to handle up to 100A of continuous current and operate within a 5V to 26V DC range, this module is perfect for powering large motors, switching battery banks, or managing high-wattage LED arrays.

    Key Features

    • Massive 100A continuous current handling

    • Supports wide input voltage from 5V to 26V DC

    • Logic-level PWM compatible for precise control

    • Ultra-low internal resistance for minimal power loss

    • Compact and rugged for industrial and DIY use

    • Supports fast switching for motor speed control and dimming

    • Heat-efficient design with strong reliability

    Specifications

    • Current Rating: 100A continuous

    • Voltage Range: 5V – 26V DC

    • MOSFET Type: N-Channel

    • Control Signal: Logic-level / PWM

    • Dimensions: 16mm x 13mm

    • Mounting: Through-hole

    • Operating Temperature: -40°C to +85°C

    Applications

    • Electric motor control in robotics, automation, and e-bikes

    • Battery pack switching for high-capacity lithium systems

    • LED lighting arrays with heavy current demand

    • Smart energy systems (solar, off-grid DC circuits)

    • RC and industrial automation systems

    • High-power DC load control in custom electronics
