Description
The S3003 Standard Servo Motor is a dependable analog servo designed to provide precise control and strong torque in a standard form factor. Known for its durability, stability, and cost-effectiveness, this servo is ideal for RC vehicles, robotic arms, and automation systems. Its smooth motion and compatibility with most control systems make it a favorite for both hobbyists and educational projects.
Key Features
- Standard Size: Fully compatible with most RC models and robotic kits
- Durable Construction: Built for long-lasting and consistent performance
- High Torque Output: Delivers sufficient power for medium-load applications
- PWM Compatible: Easily controlled by Arduino, Raspberry Pi, ESP32, and other microcontrollers
- Precise Motion Control: Ensures accurate and stable positioning for smooth operation
Specification
- Operating Voltage: 4.8V – 6.0V DC
- Stall Torque:
- 3.2 kg·cm @ 4.8V
- 4.1 kg·cm @ 6.0V
- Operating Speed:
- 0.20 sec/60° @ 4.8V
- 0.16 sec/60° @ 6.0V
- Control Angle: Approximately 180°
- Gear Type: Plastic
- Connector: 3-pin female servo plug (Signal, VCC, GND)
- Dimensions: 41 × 20 × 39 mm
- Weight: 37 g
Application
- RC cars, planes, and boats
- Robotic arms and walking robots
- Pan/tilt camera and sensor mounts
- Small actuation and automation systems
- STEM learning and educational robotics kits
