    This high-current anti-reverse diode is designed to prevent damage from accidental reverse polarity connections in power-sensitive circuits. Rated for up to 15 A continuous current, it features a low forward voltage drop and a rugged package, making it ideal for automotive, embedded, and battery-powered applications.

    Key Features

    • Handles up to 15 A continuous current

    • Low forward voltage drop for efficiency

    • Effective reverse polarity protection

    • Rugged TO-220 style package

    • High temperature tolerance for demanding environments

    Specifications

    • Maximum Continuous Current: 15 A

    • Reverse Voltage Rating: 100 V (typ.)

    • Forward Voltage Drop: ~0.8 V @ 10 A

    • Package Type: TO-220 or equivalent

    • Operating Temperature Range: –55 °C to +150 °C

    Applications

    • Battery-powered electronic circuits

    • Automotive and vehicle electronics

    • DC power input protection

    • Embedded systems with polarity-sensitive components

    • Solar-powered and portable systems

    Why Choose This Product?

    Essential for protecting circuits against reverse polarity, this high-current diode combines robustness and efficiency. ideal for reliable embedded and automotive system designs.
