35mm Dual-Wall Heat Shrink Tubing – 2:1 Shrink Ratio, Waterproof & Adhesive-Lined

35mm Dual-Wall Heat Shrink Tubing – 2:1 Shrink Ratio, Waterproof & Adhesive-Lined

Product Overview:
Engineered for heavy-duty protection, this 35mm heat shrink tubing delivers both environmental sealing and mechanical reinforcement. Its dual-wall construction—featuring a cross-linked polyolefin outer layer and a heat-activated adhesive lining—ensures a reliable, watertight seal over cables, connectors, and splices in demanding environments.

Key Features:

• 2:1 Shrink Ratio
  Reduces to half its original diameter with heat, conforming tightly to irregular shapes and surfaces.

• Dual-Wall Design
  Combines a tough outer jacket with an inner thermoplastic adhesive that melts, flows, and solidifies for a permanent seal.

• Waterproof & Pullout Resistant
  Seals against water, dust, and debris while offering excellent strain relief and resistance to cable slippage.

• Stress Relief at Bend Points
  Ideal for connectors and joints prone to flexing—extends cable life and enhances joint durability.

Technical Specifications:

• Nominal Diameter (Pre-Shrink): 35mm

• Shrink Ratio: 2:1

• Material:

  • Outer Layer: Cross-linked polyolefin

  • Inner Layer: Thermoplastic adhesive

• Shrink Temperature: Begins at ~70°C, full shrink at ~110°C

• Operating Temperature: -55°C to +125°C

• Environmental Protection: Waterproof, dustproof, vibration-resistant

Applications:
Recommended for automotive, marine, aerospace, and industrial environments where strong environmental sealing and strain relief are critical.
